VScom 800E PCIex
(PCIex-800E, Replaced by CP-168EL-A PCIe)

8x RS-232

VScom 800E PCIex, a 8 Port RS232 PCI Express x1 card, 16C950 UART

	Features

	Specifications

	Ordering Information

	Drivers & Documentation

	Datasheet

	Inquiry this product

	View Larger Image

The VScom 800E PCIex is an add-on card for PCI Express, providing eight serial ports. These high speed serial ports with their 128 byte long FIFO are best for high speed communication, even in heavy loaded systems. Many unique features reduce the system load. They also allow very unusual speed settings such as 500.000bps.

Read the News Article…

Features
Phased Out, no longer available PCI Express x1 8x RS232 16C950 (128 Byte FIFO) 921 kbps PCI Plug and Play Drivers for Windows 2000 to 7/2008R2 Use connection cable OPT8D-M or OPT8C
Back to Top
Specifications
Hardware Specifications
Ports	8x RS232 (RxD, TxD, RTS, CTS, DTR, DSR, DCD, RI)
UART	8x 16C950 (128 Byte FIFO)
Address	Plug and Play
Interrupts	PCI Plug and Play, only one interrupt per card
Speed	max. 921 kbps
Bus interface	PCI Express x1
Connectors	1x DB62, `optional adapter cable or box`
Temperature	0°C - 55°C
Back to Top
High Performance Features
FIFO	adjustable FIFO length, 1 up to 128 Bytes separate adjustable Rx and Tx
Handshake	RTS / CTS DTR / DSR Xon / Xoff all handshake automatic on Chip
Speed	1 bps up to 921 kbps unusual Baudrates possible Multiplication factor for legacy applications
Access	high speed access via Memory
UART	UART emulation of 8250 up to 16850
Back to Top
Operating Systems
Windows XP up to 7	VScom high performance serial driver, x86 and x64 Editions
Server 2003 up to 2008 R2	VScom high performance serial driver, x86 and x64 Editions
Linux	Kernel 2.6.35 and up: built-in support
Back to Top
Ordering Information
4504	VScom 800E PCIex
Back to Top
Options
705	OPT8D-S connection cable DB 62 on 8 x DSUB 9 male (with screws)
404	OPT8D-M connection cable DB 62 on 8 x DSUB 9 male (with nuts)
706	OPT8C connection cable DB 62 on 8 x DSUB 25
704	OPT8M9 connection box DB 62 with 8 x DSUB 9
Back to Top
Packaging
Packing list	VScom 800E PCIex card CD, English documentation
Back to Top

You can purchase VSCOM's products easily from a wide variety of leading technology distributors or partners. Please call us or contact us by mail to find the best ordering method for your needs.

* Specifications are subject to change without notice.
